1080P USB PTZ Camera 3X Optical Zoom Video Conference Camera Work with Facebook YouTube OBS for Church Education Live Streaming
3x optical zoom
Sleek and intelligent design
Plug & Play USB Connectivity
Crystal clear HD1080P image quality
Accurate, smooth and silent PTZ Movement
Preset: 10 via IR remote setting (255 via RS232)
Superior quality with Full Glass Lens Material
129° wide field of view with no video distortion
1/2.9 inch high quality, 2.1 MEGA PIXEL (16:9) CMOS sensor
Support ceiling mount, wall mount and tripod mount (Reverse mountable)
2D and 3D NR for best video quality in different lighting conditions
Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control
Compatible with most leading video conferencing software and platfom
Camera Parameters:
Product No. | TEVO-VHD3U |
Image Sensor | 1/2.9 inch CMOS |
Effective pixel | 2.1 mega pixel(16:9) |
Horizontal Resolution | 1080P30/25, 720P30/25 |
Signal standard | NTSC/PAL |
Zoom | 3x optical zoom |
Focal length | F=3.35-10.05mm |
Horizontal Angle | Near-end 117°～Far-end 35.1° |
Gain control | Auto/manual |
Focus | Auto/manual |
SNR ratio | ≥50dB |
Shutter speed | 8 to 1/10000s (auto) |
Preset position | IR remote control supports 10 presets Visca Protocol supports 64 presets |
Pan/Tilt movement range | Pan: 350°(max speed 80°/S), Tilt: 180°(max speed 60°/S) |
Control terminal | RS-232, RS485 |
Control Protocol | VISCA, PELCO-D, PELCO-P (RS-232, RS485) |
Video output | USB |
Video Compression Format | YUV, MJPEG, H.264 |
Noise Reduction | 2D/3D |
Work temperature | 0°C-~+40°C |
Storage temperature | -20°C~60°C |
Buad rate | 9600/38400bps |
Decoder | Built-in |
Address set | 1~64 |
Installation | Support desktop, Tripod, Wall mount and Ceiling mount |
Power supply | DC12V/ 2A |
Power consumption | 12 W |
Net weight/Gross weight | 1.5kg/2.85g |
Dimension(LXWXH) | 260*175*180 mm /296*225*218mm (before / after packing) |
Accessories | DC 12V Power adaptor, IR remote control, Manual, USB cable, Ceiling brackets & screws. |
What's in the Box?
1 X Camera1 X DC 12V power adaptor1 X IR remote control1 X Manual1 X USB cable1 X Brackets & screws
