Dia. 200mm*2 units red green led traffic lights With Cobwen Lens
Application: Red Green Traffic Light is widely used in vehicle road, railway, cross road, parking lot etc, to indicate whether vehicles can go or not.
Technical Parameters:
1. Color: Red, Green
2. LED quantity: Red:61pcs,Green: 61pcs
3. Light Intensity: red: ≤305cd , green: ≤579cd
4. Wave Length: red:625±5nm, green: 505±5nm
5. Power Fact: >0.9
6. Viewing Angle: 30°
7. Power: red: ≤3W, green:≤5W
8. Working Voltage: 85-265VAC or 9-36VDC
9.Housing Material: Polycarbonate
10. CERTIFICATES: FCC, CE, IP65, ROHS
11. Installation method: Vertical or Horizontal
12.Housing Size: 250*500*100 mm
Features:
Detail Images:
Dimension Figure:
Terminal Connection Sketch:
Packing Info:
1. 1pcs 200mm red green light
2. 2pcs Sun Visors
3. 8pcs M4x10 Screws
4. 4pcs M4x20 Screws
5. 2pcs L Brackets
6. 1pcs Wiring Box And Gasket
Company Information:
BBM Technology Company Limited is a professional manufacturer of LED traffic products. We specialized in LED traffic singal light ,traffic arrow traffic light ,related traffic light modules, solar road stud ,traffic countdown timer, ,LED pixels cluster ,LED arrow board, traffic controller, led gas price display etc.
Our company focuses on technological innovation, has own research and development team, with the purpose of "making roads safer", development of new intelligent traffic products. We have our own factory, so we can provide the factory direct price and guarantee the good quality of the products. We have CE, FC, RoHS, IP65 certificates for our products.
