Specification :
Unlock way : Mechanical key / APP (Bluetooth)
Work voltage : 3x CR123A ( Not included )
Material : Aluminium Alloy ( lock body ) + Copper ( Lock core )
Key Specifications/Special Features:
1,Simple, DIY installation. Install in about 5 minutes ,no need take any hole;2,Bank level security . Using OTP technology , each unlock use differeny password
3,Locks automatically by your setting.
FUNCTION NOTE:
1.The lock can connect with the phone via bluetooth, and control by WeHere APP. If you can't download the APP, please contact with me.
2.The look power by CR123 battery(not include in the package).
3.If you want to control the lock by phone network, you need to buy a tuya zigbee gateway. Our lock support TUYA/Smartlife APP.or If you want to control the lock by phone TTlock app, you need to buy a G2 ttlock gateway.
4.Our lock include 2 keys, if you need more keys, please contact with me, add 6 USD per key.
5.The lock will lock the door automatically by setting lock time on APP.
Note: the cover logo "smart lock" "K" sendat random. The silver type logo is silver, and the black type logo is black.
The Gateway is Tuya zigbee wireless gateway, look like the last picture show.
This is a EU LOCK cyclinder, please check your lock before placing orders.
Make sure your lock fit for this cylinder before placing orders.
Tuya Wifi Gateway
TUYA Zigbee hub that connects to a variety of Zigbee smart products and is the bridge and control center for smart homes. By connecting to the router, TYGWZ-01 enables communication with the cloud and mobile app, allowing users to easily view and control various smart devices in the home that use the Zigbee protocol.
Parameter:
- Chip: EFR32MG1B232
- Standard: IEEE 802.15.4
- Frequency: 2.4~2.485GHz
- Maximum output power: 19dBm
- Dynamic output power: >35dB
- Open line of sight transmission distance: >300m
- Frequency error: ±15ppm
- Theoretical transmission rate: 250kbps
- Receive sensitivity: typical -102dBm, PER<10%
- Total number of channels: 16 Channel number: 11~26
- Network topology: Supports star, tree, mesh network
- Antenna: default PCB onboard antenna Firmware upgrade: Support OTA
Electrical Specification
- Adapter: 110V~240V AC, 5V/1A DC
- Working voltage: 1.8V ~ 3.3V
- Working temperature: -10-55°C
- Working humidity: 10%-90%RH (non-condensing)
- Storage temperature: -20-60°C
- Storage humidity: 5%-90% RH (non-condensing)
Note: not include power adapter.Note: not include power adapter.
Overview
TTLOCK Wifi Gateway
Feature
1. Wifi & internet remote control
2. Free SDK and API
3. Change password remotely via internet
4. When the user opens the door, the administrator will receive a real-time prompt message
5. Wifi & mobile internet remote control
6. This smart app can be used as time attendance
7. Standby time is up to 12 months, when the battery is about to run out, the system will have sound and light warning
8. Remotely view the status of the door, open or closed
9. AES 128-bit encryption to prevent all hacker hidden dangers
