Affordable Wholesale Dahua 5MP HDCVI Camera 1/2.7" CMOS 2pcs IR LEDs Smart IR 80 meters Built-in MIC Outdoor camera Aluminium Case Security camera

In Stock

Affordable Wholesale Dahua 5MP HDCVI Camera 1/2.7" CMOS 2pcs IR LEDs Smart IR 80 meters Built-in MIC Outdoor camera Aluminium Case Security camera

SKU: 4000069858851

Safe Payment Guarantee:

Dahua 5MP HDCVI Camera 1/2.7" CMOS 2pcs IR LEDs Smart IR 80 meters Built-in MIC Outdoor camera Aluminium Case Security camera

6mm 8mm are in stocks, welcome order~

Features:System OverviewExperience superior 5MP video and the simplicity of reusing existing coaxial infrastructure with HDCVI. The Lite series 5MP HDCVI camera features a compact design and offers a high quality image with rich details at a friendly price. It offers various vari-focal/fixed lens models with a multi-language OSD and HD/SD switchable output. Its structural flexibility and high cost-performance makes the camera an ideal choice for SMB solutions.

HAC-HFW1500TL-A

5MP HDCVI IR Bullet Camera

> Max. 20fps@5MP
> Built-in mic
> HD and SD output switchable
> 3.6mm fixed lens (2.8mm, 6mm, 8mm optional)
> Max. IR length 80m, Smart IR
> IP67, DC12V

Product Show:

Specifications:

Camera

Image Sensor

1/2.7" CMOS

Effective Pixels

2592(H)×1944(V), 5MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/25~1/100000s

NTSC: 1/30~1/100000s

Minimum Illumination

0.02Lux/F1.85, 30IRE, 0Lux IR on

S/N Ratio

More than 65dB

IR Distance

Up to 80m (262feet)

IR On/Off Control

Auto / Manual

IR LEDs

Lens

Lens Type

Fixed lens / Fixed iris

Mount Type

Board-in

Focal Length

3.6mm (2.8mm, 6mm, 8mm optional)

Max Aperture

F1.85

Angle of View

H: 77.5° (98°/49°/37°)

Focus Control

N/A

Close Focus Distance

1400mm (900mm/2800mm/4500mm)

55" (35''/110''/177")

DORI Distance

Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.

DORI

Definition

Distance

Detect

25px/m

(8px/ft)

2.8mm: 63m(207ft)

3.6mm: 80m(262ft)

6mm: 120m(394ft)

8mm: 160m(525ft)

Observe

63px/m

(19px/ft)

2.8mm: 25m(82ft)

3.6mm: 32m(105ft)

6mm: 48m(157ft)

8mm: 64m(210ft)

Recognize

125px/m

(38px/ft)

2.8mm: 13m(43ft)

3.6mm: 16m(53ft)

6mm: 24m(79ft)

8mm: 32m(105ft)

Identify

250ppm

(76px/ft)

2.8mm: 6m(21ft)

3.6mm: 8m(26ft)

6mm: 12m(39ft)

8mm: 16m(52ft)

Pan/Tilt/Rotation

Pan: 0° ~ 360°

Tilt: 0° ~ 90°

Rotation: 0° ~ 360°

Video

Resolution

5MP (2592×1944)

Frame Rate

20fps@5MP, 25/30fps@4MP, 25/30fps@1080P

Video Output

1-channel BNC high definition video output / CVBS video output (Can switch)

Day/Night

Auto (ICR) / Manual

OSD Menu

Multi-language

BLC Mode

BLC / HLC / DWDR

WDR

DWDR

Gain Control

AGC

Noise Reduction

White Balance

Auto / Manual

Smart IR

Auto / Manual

Certifications

CE (EN55032, EN55024, EN50130-4)

FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)

UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Interface

Audio Interface

Built-in mic

Eelectrical

Power Supply

12V DC ±30%

Power Consumption

Max. 4.9W (12V DC, IR on)

Environmental

Operating Conditions

-40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH

* Start up should be done at above -40°C (-40°F)

Storage Conditions

-40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH

Ingress Protection & Vandal Resistance

IP67

Construction

Casing

Aluminium (Front face) + Plastic (Body)

Dimensions

80.2mm×76.2mm×198.9mm (3.16"×3"×7.83")

Net Weight

0.28kg (0.62lb)

Gross Weight

0.42kg (0.93lb)

If you need other models that are not found in our store, you can send message to us the model number you need , we will check and quote our best price for you.

MadridStore

Affordable Wholesale Dahua 5MP HDCVI Camera 1/2.7" CMOS 2pcs IR LEDs Smart IR 80 meters Built-in MIC Outdoor camera Aluminium Case Security camera

HAC-HFW1500TL-A
