Home Video Door Phone Doorbell Intercom System,Aluminum alloy,Motion Record
1:Monitoring outside by press monitor button any time
2,Unlock button on Monitor,the unlock time is adjustable
3,Dual way intercom between monitor and doorbell
4,Call transfer between monitor and monitor when up to 2 monitos are connected
5,3 Languages: English / русский / Español
6,upport images / videos playback, support up to 32GB memory card
7,Multiple system supported,it could connect 4 monitors ,2 doorbell cameras ,2 CCTV camera and 2 Alarm sensors.
Indoor Monitor Features
Monitor:10 Inch,16:9 Display
Storage: Built-in memory can save 80 pictures, support external max. 32GB SD card
Intercom mode ：Hands-free dual-way intercom
Delay calling time 120s
Keypad touch sensor button
Power input External power DC12V
Power Consumption Standby:1W; Working:5W
Material Aluminum alloy
Recording picture:jpeg format;video:avi format
Operation Temp. -10ºC +60ºC
Installation Surface mount
With 1200TVL HD Doorbell Camera
Homefong Video intercom System is with 1200TVL Doorbell,which help you view clearly.
Features
Metal Material
Touch Sensor Button with Blue light
Slim Design
Wide Angle 100 Degree
Dual-way Intercom,call transfer between monitor and monitor,monitor and doorbell
If the visitor want to talk with another person,the call should be transfered to another monitor in another room,downstairs or upstairs.Internal communication function requires at least two indoor and one outdoor unit to be connected.
Multiple Language Supported
3 Languages: English / русский / Español
Record Function Supprted
When someone ring the doorbell,the monitor will record automatically.
Motion Detection
When the motion is detected,the monitor will record automatically.
Outdoor Doorbell Feature
Waterproof Level：IP65
Material：Aluminum alloy
Operating temperature：-40ºC +60ºC
Camera：1200TVL
Day Night Vision：Yes
Connection Way
Electronic Lock with 3A Power Supply
Lock Specification
Suitable for all sorts of access control systems and Video door systems
Suitable for : home, offices, schools, hotels, factories, warehouses, etc
Voltage:DC12V+-20%
Magnetic distance:≥10mm
Automatically detects door status.
Can be installed on the left door, right door, interior door, outside the door and other doors
Operating Mode: NO
DC 12v Power Supply Control 3A 110-240v
Voltage range input regularly from AC 110V - 240V 50~60Hz DC output: Stabilizator DC12V/ 3A Controls electric lock directly Power: 36W Output Stability: 0.5% Typical Operating Temperature: -20C~65C Adjustable Locking Delay: 0~15sec Material: Metal Outside iron shell dimension:120mm*95 mm*38mm Net Weight: 315g
The lock support RFID Unlock from both side
Set 2 with Electric Lock and 3A power supply
If you choose set 2 with lock ,the below lock and accessories will be added
Connection
