Support Multi-mode input, AHD, IP, Analog, TVI, CVI Camera.Support VGA, HDMI HD output;Support Cloud technology, easy to achieve a variety of network penetration;
Support IOS, Android mobile monitoring;
Support more than 20 languages(English, Finnish, French, German, Italian, Korean, Japanese, Polish, Portuguese, Russian, Spanish, Thai, Chinese, Traditional Chinese, Turkish, etc.)
Note: For AHD, it is a 1080N DVR, can compatible with 1080P AHD Camera, but can not get the best image of the 1080P AHD camera. Hope you can understand.
System
Model: A1116N
Main processor: Hi3521AScreen display: 1/4/8/9/16
Video compression: H.264(High Profile);
Encode: 16*1080N (12fps)
Decode: 16*1080N (12fps )ONVIF: Support (IP)
Multi-mode input: Pure AHD: 16*1080N; 8*1080N
Mixed: 8*1080N + 8*960P
Pure IP: 8*1080P+8*960P; 16*960P; 4*3M; 4*5MAudio compression: G.711A
Monitor quality: Max 1920*1080Motion Detection: Each screen can be set to 192 (16 × 12) detection area; multi-level sensitivity can be set
Recording and Playback
Record mode: Manual>alarm>motion detection>timing
Playback Channels: 16 (pure local input mode)
Storage and backup
Record storage: HDD, NetworkBackup mode: Network backup/USB HDD/ USB writer/SATA writer
Interface
Video input: 16 BNC
Video output: 1ch VGA,1ch HDMI
Audio input: 2ch RCA
Audio output: 1ch RCA
Alarm input: No
Alarm output: No
Network interface: RJ45 10M/100M Adaptive Ethernet port
PTZ control: RS485; support multiple PTZ protocols
USB: 2 USB ports
Hard disk: 1 SATA (Max support 6T)
Notice: The default power supply that the device comes with is 12V 2.5A, it supports Max 3T hard disk, if you want to use a 6T hard disk, need to replace the power supply with a 12V 4A by yourself.
General
Power: 12V/2A
Humidity: 0-55 Centi-Degree 10%-90%RH
Dimension: 26 x 23.3 x 4.3cm
Weight: Around 1.5KG
Package Content
1 x AHD DVR
1 x USB Mouse
1 x User Manual
1 x DC12V 2A Adaptor (100V - 240V input)
Note:
1. This items have three power adapter, US type, UK type and EU type. Please leave a message in the order to tell us which type that you need.
2. This product do not including Hard Disk.
Monitor Real Picture
Note: This is SerialNo, it is the unique SerialNo of this DVR. We need this SerialNo to connect with our cellphone and computer.
Multi-Language Option:
Website Screen Shot
CMS Software Screen Shot
Smartphone APP Screen Shot
