Indoor Monitor Specification
Resolution;800*480
Material:ABS
7 Inch color LCD video intercom monitor
Unlock electronic lock
Monitoring
Dual Way intercom between monitor and doorbell
low power consumption, no radiation
Outdoor Doorbell
Day Night Vision
Working temperature:-20-+55 degree
Built-in microphone supports bi-directional communication between indoor monitor intercom and outdoor doorbell.ultra-clear sound quality without any noise.
2 Unlock Button on the monitor
The monitor could connect with 2 locks separately, 1 lock could connected with doorbell,the other lock could connected with monitor directly
Electronic Lock and Exit Button with 3A Power Supply
Suitable for all sorts of access control systems and Video door systems
Suitable for : home, offices, schools, hotels, factories, warehouses, etc
Voltage:DC12V+-20%
Magnetic distance:≥10mm
Automatically detects door status.
Can be installed on the left door, right door, interior door, outside the door and other doors
Operating Mode: NO
The lock support RFID Unlock from both side
Touch operated one piece Access Control 3A Power Source
This product is designed to be nice and convenient,easy to install,with less wires and built-in high-end intelligent power chip,and is produced by professional and advance process.
Applicable to building intercom,video intercom,video door phone ,various access control units,various electric locks,monitoring probes.
Parameters
1.AC input: AC110-240V 50/60HZ
2.DC input: DC12V/3A
3.With NO/NC/COM port,convenient to connect all kinds of electric locks.
4.With time-delay regulation feature,freely regulated in 0-15 seconds.
5,size:85mm*85mm*42mm
Connection
