8MP 4K Feature
Supporting Face detection, Humanoid detectionn, and supports customization of other smart functions;
8.0MP HD Black light illumination resolution, clear and fine images;
Support 2D/3D noise reduction, digital wide dynamic;
Advanced H.265(Compatible with H.264) video compression, Super low rate, high definition quality of image;
Professional anti-lightning, conform to GB/T17626.5 and IEC61000-4-5;
Support ONVIF, access third party;
Support various mobile monitoring(iPhone, Android);
Size:
| OS |
Parameters |
8MP 4K |
| kernel |
System |
Linux |
| Processor |
Mstar |
|
| Video |
Image sensor |
8MP Super Low illuminance COMS image sensor |
| Video Codec |
H.265 main profile and baseline |
|
| LEN |
3.7mm |
|
| IR LED |
NA |
|
| IR distance |
NA |
|
| Support mobile phone |
All phone |
|
| P2P |
PHONE,IE,P2P Client global Internet |
|
| Video Resolution |
First stream:4K 8MP(3840*2160)@15fps/5MP(2880*1624)@25fps/4MP(2560*1440)@25fps/ 3MP(2304*1296)@25fps/2MP(1920*1080)@25fps can be set |
|
| 4K 8MP(3840*2160) |
||
| Second stream:1280*720,800*448,704*576,640*360 |
||
| Three stream:640*360/352*288 |
||
| frame rate |
8MP:15fps,5MP:25fps,4MP:25fps,3MP:25fps,2MP:25fps |
|
| Video compression |
32Kbits/S～12280Mbits/S |
|
| Min.Lux |
Color>0.01 LUX B&W<0 LUX |
|
| Store |
SD card |
NA |
| Client/Browser |
Support |
|
| Record |
Client |
support |
| Browser |
Support |
|
| SD CARD |
not Support |
|
| Playback |
Client |
support |
| Browser |
Support |
|
| SD CARD |
not support |
|
| SD Card |
|
not support SD card |
|
|
||
| Audio |
Audio input |
Mic is builded in camera |
| Audio output |
SNA |
|
| Audio Codec |
G.726/G.711 |
|
| Internet |
Internet face |
10Base-T/100Base-TX, POE |
| Network Protocol |
TCP/IP,https,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP |
|
| Access Protocol |
ONVIF |
|
| Alarm |
Motion detection |
At most 4 respective regions |
| Alarm linkage |
Alarm picture send E-mail, alarm images upload FTP server |
|
| Snap |
Time snap |
Regular support capturing images to the FTP server |
| safe |
User management |
Provide three levels of rights management (admin, user, guest), support to modify login user name and password |
| Other |
Inter Power,consumption |
DC12V 2A/POE (The package does not provide a power adapter) |
| Working temperature |
-40℃ ～ +55℃ |
|
| Working Humidity |
10-95% |
|
Working With NVR For 24/7 Reliable Recording
