indoor parameters
*Model:V70MT-HD
Monitor:IPS HD touch screen
Resolution:1024*600
Power supply:15V1.2A(support POE power supply)
Power :Standby: ≤1W Operating: ≤10W
Intercom / Monitoring time:120 s /60 s
Connection Wire:CAT5E(100M)
Ringtones : 10
Language: Russian /English /Chinese
WIFI: TUYA APP
Motion detection: Support
Extended storage:64GB
Installation:Wall mount
Material:Tempered glass panel+ABS plastic
Size:195*132*18mm
outdoor parameters
Model:IDS
Resolution:2.0mp
View Angle:120°
Night vision sensitivity:0.001Lux
Night vision distance:10M IR night vision
Rainproof level:IP55
Power supply:From monitor supply
Operating temperature:-30℃~60℃
Connection mode:Ca5 Network cable
Maximum distance:100M
Unlock type:Remote contral/RFID card Unlock
The quantity of ID card:500pieces
Installation:Surface mount
Material:Aluminum alloy cover+ABS plastic
Size:180*98*45mm
Digital HD WiFi Tuya video intercom doorbell
1080P HD Camera,High Resolution Screen,High Quality
Note: Our indoor monitor or outside unit only can work with our products,thank you!
Product features
*1080P digital HD camera & 120°wide angle.
*10M IR night vision/ motion detection/message
*Digital HD indoor unit adopts IPS screen
*Not only Support Intercom ,unlock, monitor, take photos, recording, playback,
indoor group call, But also Support Tuya App remote operation of the above function
*Support RFID card unlock，A maximum of 500 user cards are supported
Support mobile APP with monitor
when visitor press the doorbell,your phone will receive the APP notification, you can see,hear and speak to anyone at your door, even remote unlock via your smartphone in everywhere. It is convenient for elder or people with reduced mobility to open the door.
(one device can be added and connected to several mobile phones in the meantime,and up to 4 mobile phones are allowed to open and view the outdoor unit in the meantime)
Automatic recording
When a visitor presses the doorbell or triggers motion detection, the doorbell camera automatically records video or photos and saves them in an additional TF card to protect your home every day. · (Our indoor machine is not equipped with 32G memory card)
Three scenario modes can be set according to your actual situation
Waterproof (rain cover)
Work stable in rainy,cloudy,cold and snow day.
Built with 1080P camera,anti-oxidation aluminium alloy panel,Rainproof,Dust proof,and Anti-vandal.
RFID card function, quick unlock
Support up to 500 user cards ID
Multiple ways of unlocking
With this intercom System,you can use RFID Cards, Password, Monitor and Phone to open the Door,
which will be more convenient!
One key to unlock
This video intercom can connect to the electric lock.
You can open the door with the indoor monitor. Very convenient!
POE Switch Wiring Diagram
NOTE:The system support 4 pcs outdoor unit + 2 pcs camera connect +6 pcs monitor
* Multiple outdoor units /IP network camera,It also support powered by POE
* The powered from monitor, and the outdoor unit don’t need separate power
* Part of the equipment in the wiring diagram is not included in the package, need to buy additional, details can contact customer service
Pcking list
1x 7 Inch indoor unit
1x Outdoor camera
1x Indoor Hanging plate
1x Adapter
1x Test network cable
1x Packing of screws
4xRFID card
1x English Manual
